4 Replacement Procedures 4.23 Fluorescent Lamp
4-94 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
7. Bend the TCP attaching to the source board and secure it with the two screws.
Figure 4-79 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (18)
Figure 4-80 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (19)
Do not hold the edge.
Do not hold the edge.
Screw
Screw
