4.22 Wireless LAN Antenna/Speaker/Hinge 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-63
Figure 4-44 Removing wireless LAN antennas
Glass Tape
Wireless LAN
antenna cable
Wireless LAN antenna
Glass Tape
Glass Tape
[Sharp
-
made LCD]
Sponge
Sponge
Glass Tape
Wireless LAN
antenna cable
Wireless LAN antenna
Glass Tape
Glass Tape
[LG Philips
-
made LCD]
Gasket
Aluminum Tape
Aluminum Tape
