4 Replacement Procedures 4.7 Cooling Fin/CPU
4-22 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
2. Remove the following screws securing the CPU holder on the CPU.
? M2x4B BIND screw x3
Figure 4-12 Removing CPU Holder
M2x4B BIND
CPU Holder
