4.2 Battery Pack/PC Card 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-9
Installing the battery pack
The following describes the procedure for reinstalling the battery pack (See Figure 4-1).
CAUTION: There is a danger that the lithium ion battery pack may explode if not
fitted, operated, handled, or disposed correctly. Collect the spent battery
packs. Use only the batteries approved by Toshiba.
NOTE: Check visually the battery terminals and clean off any dirt with a dry cloth.
1. Turn off the power of the computer.
2. Disconnect the AC adapter and all other external devices from the computer.
3. Fit the connector of the battery pack to the computer’s connector and push it until
click sounds.
