4 Replacement Procedures 4.23 Fluorescent Lamp
4-78 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
8. Remove the lamp wire from the wire guide of the mold frame.
Figure 4-60 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (8)
Lamp wire
