4 Replacement Procedures 4.23 Fluorescent Lamp
4-74 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
4. Remove the four bottom hooks and four side hooks (left and right). Then remove the
top chassis from the mold frame.
Figure 4-56 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (4)
Side hook
S
ide hook
Bottom hook
