3.20 ONLY ONE TEST 3 Tests and Diagnostics

3-44 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)

Subtest 03 GP Button

This subtest checks if the GP buttons work properly.

The following message appears in the display.

Press [Console] Button!

Press the indicated button, then following message will appear in the display.

Press [Console] Button! OK

As the same way, press the indicated buttons and run the button test.

If wrong key is pressed, following message will appear in the display.

Press [Console] Button! NG

Functionkeys = XXXX

Press any key!

Pressing any key, indication of pressing button will appear in the display again.

Unless the right button is pressed, this operation is repeated.

After checking all the button (Console Button, Presentation Button, Intternet Button),

return to the ONLY ONE TEST menu automatically.

Subtest 04 Kill Switch

This subtest checks if the Wireless communication switch works properly.

If the test is started with the switch ON, following message appears in the display.

Kill switch is set to a start position (OFF)

Slide the switch to OFF position. Then, following message appears in the display.

KILL SWITCH ON !!

Slide the switch to ON position. Then, following message appears in the display.

KILL SWITCH OFF !!

After Sliding the switch to OFF position, return to the ONLY ONE TEST menu

automatically.

Subtest 05 USB
