4. List of simulations

Main

code

Sub

code

Content

1

01 Mirror scanning

02 Optical system sensor check

03 Lens operation check

04 Lens operation aging

2

01 ADF aging

02 ADF sensor check

03

ADF individual load operation check (Paper feed

motor forward rotation)

04

ADF individual load operation check (Paper feed

motor reverse rotation)

05

ADF individual load operation check (Transport

motor forward rotation)

06

ADF individual load operation check (Transport

motor reverse rotation)

08

ADF individual load operation check (Paper feed

solenoid)

10

ADF individual load operation check (Paper feed

motor normal rotation + paper feed solenoid)

3

02 Sorter sensor check

03

Sorter individual load operation check (Transport

motor)

04 Sorter individual load operation check (Bin motor)

05 Sorter individual load operation check (Buzzer)

06

Sorter individual load operation check (Alignment

motor) (SF-S54 only)

07

Sorter individual load operation check (Pinch

hold motor) (SF-S54 only)

5

01 Operation panel display check

02 Heater lamp check

03 Copy lamp check

04 DL lighting check

05 BL lighting check

6 01 PSPS operation check

7

01 Warm-up time display and aging

04 Warm-up omitting

06 Intermittent aging

08 Warm-up time display

8

01 Developing bias output

02 Main/transfer charger output/grid check (ME)

03 Main/transfer charger output/grid check (PE)

04 Main/transfer charger output/grid check (T/S)

07 Separation charger output

10 — Toner motor aging

14 — Trouble cancel (Excluding U2 trouble)

15 — Waste toner full (blinking) cancel

16 — U2 trouble cancel

20 — Maintenance counter clear

21 01 Maintenance cycle setting

Main

code

Sub

code

Content

22

01 Maintenance counter display

02 Maintenance preset counter display

03 JAM memory display

04 Total JAM counter display

05 Total counter display

06 DV counter display

07 DV preset counter display

08 ADF counter display

10 Staple counter display

11 Toner concentration correction counter display

15 Trouble memory display

24

01 JAM memory/total JAM counter clear

02 Trouble memory clear

04 ADF counter clear

05 Staple counter clear

25

01 Drive system check

02 Automatic developer adjustment

26

05 Counter mode setting

06 Destination setting

07 Drum sensitivity setting

10 AE document density setting

13 Warm-up mode setting

18 Toner save mode setting

20 Rear edge void setting

29 AC power voltage setting

30 01 Copier sensor check (paper sense)

42 — Developer counter (counter clear)

43 01 Fusing temperature setting

44

01 Process control operation setting

05 Grid voltage correction test

06 Grid voltage correction compulsive execution

07 Image density/drum mark sensor operation test

08 Process control data display

09 Process control data display (Latest value)

10

Grid voltage correction (Drum surface/patch)

data display

11 Initial grid bias setting

12 Copy operation check with process control OFF

46 01 Exposure adjustment

47 —

AE sensor characteristics measurement (AE

sensor gain automatic adjustment)

48

01 Front/rear magnification ratio adjustment

02

Paper transport direction magnification ratio

adjustment (Mirror speed correction)

50

01 Copy lead edge adjustment

02 Lead edge adjustment (Simple type)

51 02 Resist amount adjustment

53

01

ADF stop position adjustment value (normal

paper) setting

04 ADF resist sensor, width sensor adjustment

06 ADF timing sensor adjustment

54 03 Take-out buzzer setting

8 – 2
