(3) 10-bin staple sorter (10-bin SS)

Type Copier installation type/hanging type

Distribution system Bin shift system by lead screw

No. of bins 10 bins (The top bin is commonly used

for non-sort.

Capacity 30 sheets for each bin

(A4, 8 1/2" × 11", 80g/m

)

100 sheets for the top bin

Sort 30 sheets (A4, 8 1/2" × 11")

15 sheets (B4, 8 1/2" × 14", 8 1/2" × 13")

15 sheets (A3, 11" × 17")

80g/m

(21 lbs.)

Grouping 20 sheets (A4, 8 1/2" × 11")

15 sheets (B4, 8 1/2" × 14")

15 sheets (A3, 11" × 17"),

80g/m

(21 lbs.)

Staple sort 30 sheets (A4, 8 1/2" × 11")

15 SHEETS (B4, 8 1/2" × 14")

15 sheets (A3, 11" × 17")

80g/m

(21 lbs.)

Paper size Non-sort A3 ∼ A6R

11" × 17" ∼ 8 1/2" × 5 1/2"

Sort/group A3 ∼ A5

11" × 17" ∼ 8 1/2" × 5 1/2"

Staple sort A3, B4, A4, A4R, B5, 11 × 17",

8 1/2 × 14", 8 1/2 × 11", 8 1/2 × 11R

Alignment (Sorting) Max. shift 2mm (Alignment operation)

Paper transport Center reference

Paper loading Face up

Paper weight Non-sort 49 ∼ 128g/m

(13 ∼ 34 lbs.)

Sort/group/staple sort 56 ∼ 80g/m

(15 ∼ 21 lbs.)

Dimensions 390(W) × 542(D) × 400(H)mm

15-23/64" (W) × 21-11/32" (D) ×

15-3/4" (H)

Weight About 11.5kg, 15kg (33.1 lbs.) [including

the installation kit]

Power source DC24V (1.5A) supplied from the copier.

Power consumption Max. 36W

Staple section

Type Copier stapler

Stapling time 1.8 sec

No. of stapled sheets 30 sheets (80g/m

, 21 lbs.)

Binding reference Front reference

Staple supply Cartridge (5,000 pcs.)

Staple SF-LS12

No staple/no cartridge/

no stapler detection

Available

Staple jam detection Available

Manual staple mode Available (excluding manual stapling)

Note: When installing the SF-S54, the exclusive-use desk (SF-DS17,

SF-DS17E) is required.

(4) Exclusive-use desk

SF-DS17

Dimensions 570(W) × 523(D) × 520(H)mm

Weight About 19.5kg

Functions Caster Provided

Adjuster None

Door None

2 – 5
