The above screen shows the keys that appear when a saddle stitch finisher is installed. The keys that appear will vary
depending on what peripheral devices are installed.
In addition, it may not be possible to select some keys depending what peripheral devices are installed. If your screen is
different from the screen of previous page, see the screens that follow.
Example
The screen when a finisher or saddle stitch finisher is not installed.
OK
Output
Sort
Right Tray
Offset
Tray
Group
