COPYING MULTIPLE ORIGINALS ONTO
ONE SHEET (Multi Shot)
Multiple original pages can be copied onto a single sheet of paper in a uniform layout. Select 2in1 to copy two original
pages onto one sheet, or 4in1 to copy four original pages onto one sheet. This function is convenient when you wish to
present multiple pages in a compact format, or show a view of all pages in a document.
2in1 copying 4in1 copying
B
A
A B
D
C
B
A
AB
CD
1
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
2
Select the special modes.
(1) Touch the [Special Modes] key.
(2) Touch the [Multi Shot] key.
☞ Special modes menu (1st screen) (page 44)
