AR-651/810 TROUBLE SHOOTING 5 - 88

[Procedure 2]

Is the paper pushing plate top position sensor (PI15S) working normally?

Replace the sensor.

YES

Is the paper pushing plate motor (M8S) operating at the fixed timing?

YES

Replace the saddle stitcher controller PC board.

Is there any problem with the paper pushing plate drive mechanism?

YES

Fix the mechanism.

Is the problem solved by replacing the paper pushing plate motor (M8S)?

Replace the saddle stitcher controller PC board.

YES

END

[Procedure 3]

Is the paper pushing plate motor clock sensor (PI1S) working normally?

Replace the sensor.

YES

Is the paper pushing plate motor (M8S) operating at the fixed timing?

YES

Replace the saddle stitcher controller PC board.

Is there any problem with the pushing plate drive mechanism?

YES

Fix the mechanism.

Is the problem solved by replacing the paper pushing plate motor (M8S)?

Replace the saddle stitcher controller PC board.

YES

END
