AR-651/810 TROUBLE SHOOTING 5 - 42

[EA5] Finisher stapling jam

Is there any paper remaining on the transport path in the finisher or main unit, or on the stapling tray?

YES

Remove the paper.

Is the jam cleared by taking off the staple cartridge from the finisher and removing the staple sheet

sliding it from the staple case?

YES

End

Is the connector J8 on the finisher controller PC board disconnected?

Is the harness connecting the finisher controller PC board and staple home position sensor

(PI22) open-circuited?

YES

Connect the connector securely. Replace the harness.

Is the staple home position sensor working properly?

1. Connect the connector of the staple home position sensor securely.

2. Replace the staple home position sensor.

YES

Replace the finisher controller PC board.
