5 - 33 AR-651/810 TROUBLE SHOOTING

5.1.5 Original jam in RADF

[E71] Original feeding jam

Are the pickup roller, feed roller and separation roller dirty?

YES

Clean the rollers.

Is the transport force of the rollers insufficient?

YES

Replace the rollers.

Is the original abnormally curled or folded?

YES

Flatten and set it again.

[E72] Original transport jam

[E73] Original discharging jam

Are the registration roller, read roller and exit roller dirty?

YES

Clean the rollers.

[E74] Original reversing jam

Are the read roller and reverse roller dirty?

YES

Clean the rollers.

Is the reverse flapper working properly?

Adjust the reverse solenoid.
