Available Memory
Memory Bit Write TYPE Remarks
D (data register) 0
W (link register) 1
R (file register) 2
TN (timer/current value) 3
CN (counter/current value) 4
SPU (special unit) 5 Slot No. *1
M (internal relay) 6
L (latch relay) 7
B (link relay) 8
X (input relay) 9
Y (output relay) 10
TS (timer/contact) 11
TC (timer/coil) 12
CS (counter/contact) 13
CC (counter/coil) 14
SD (special register) 16 Only in QnA
SM (special relay) 17 Only in QnA
SB (special link relay) 18 Only in QnA
SW (special link register) 19 Only in QnA
ZR 20 Only in QnA
(file register [continuous access])
*1 The slot No. is required in addition to the memory type and the address.
Convert a byte address into a word address to enter the data if the memory device of link unit is
byte address.
2 MITSUBISHI PC • 2
Set the memory to the extent of the memory range of each PC model. In case of using the
[Bit Write] memory as the bit device of the [Output Action] is [Momentary W], the other
bits will be cleared when the bit memory is output, because the [Bit Write] will be output
by one word (refer to P5-10, reference 14-7 of ZM-71SE Instruction Manual). Use [TYPE]
number to assign indirect memory for macro programs.
Available: Unavailable:
