1 - 39

1 Connection

General purpose computer

ZM-＊＊

RS-232C

RS-422

1: 1 connection

General purpose computer

ZM-＊＊

RS-422

ZM-＊＊ ZM-＊＊

1 : 1 connection

15-3 Connection by general purpose serial communication

The ZM-** can connected with a general purpose computer using the user program (exclusive

command use). Refer to ZM (general purpose serial) user’s manual in detail.

[1] When a computer and ZM-** are 1 : 1

- RS-232C can use it by less than 15m, and RS-422 (485) can use transmision distance by less than

500m.

- Interruption processing can be used. (Switch ON/OFF, the write-in key of a ten-key, screen change)

[2] When a computer and ZM-** are 1 : n (Up to ZM-** 32 sets are connectable.)

- The command point needs to be station number specified.

- Interruption processing cannot be used.(Switch ON/OFF, the write-in key of a ten-key, screen

change)
