Removalstepsofthemicroprocessor

Rotatetheheadofthescrewinthedirectionshownbyarrow1toreleasethelock;thenremovethe

microprocessor2.

Wheninstalling:Placethemicroprocessoronthemicroprocessorsocket,andthenrotatetheheadofthe

screwinthedirectionshownbyarrow

atosecurethemicroprocessor.

1080WirelessWANslotcoverandPCIExpressMiniCardforwireless

WAN

Foraccess,removethisFRU:

•“1010Batterypack”onpage58

66HardwareMaintenanceManual
