Chapter10.Partslist

Thischaptercontainsfollowinglistsoftheserviceparts.

•“Overall”onpage106

•“LCDFRUs”onpage123

•“Keyboard”onpage138

•“Miscellaneousparts”onpage140

•“ACadapters”onpage140

•“Powercords”onpage141

•“Recoverydiscs”onpage142

•“Commonservicetools”onpage147

Notes:

•EachFRUisavailableforalltypesormodels,unlessspecictypesormodelsarespecied.

•FRUwithspecicmodelslistedanddescribedasxxU(whereUisanexampleofacountrydesignator)shouldbe

usedforallmodelsendinginU.

•FRUwithspecicmodelslistedanddescribedas3Dx(where3Disanexampleofauniqueconguration)shouldbe

usedforallofthesemodels,unlessspeciccountryorregiondesignatorisspecied.

•ACRU(customerreplaceableunit)isidentiedbyasingleasterisk(*)ortwoasterisks(**)intheCRUIDcolumn.An

NintheCRUIDcolumnmeansthatthepartisnotaCRU.Asingleasterisk(*)meansthatthepartisaSelf-service

CRU;twoasterisks(**)meansthatthepartisanOptional-serviceCRU.

ExternalCRUstatementtocustomers:

Someproblemswithyourproductcanberesolvedwithareplacementpartyoucaninstallyourself,called

a“CustomerReplaceableUnit”or“CRU.”SomeCRUsaredesignatedasSelf-serviceCRUsandothersare

designatedasOptional-serviceCRUs.InstallationofSelf-serviceCRUsisyourresponsibility;youmayrequest

thatLenovoinstallsanOptional-serviceCRUaccordingtothewarrantyserviceforyourproduct.Whereyouare

installingtheCRU,LenovowillshiptheCRUtoyou.CRUinformationandreplacementinstructionsareshipped

withyourproductandareavailablefromLenovoatanytimeuponrequest.YoumayndalistofCRUsinthe

publicationsthatshipwithyourproductorathttp://www.lenovo.com/CRUs.Y oumayberequiredtoreturnthe

defectivepartthatisreplacedbytheCRU.Whenreturnisrequired:(1)returninstructions,aprepaidshippinglabel,

andacontainerwillbeincludedwiththereplacementCRU;and(2)youmaybechargedforthereplacementCRUif

Lenovodoesnotreceivethedefectivepartwithinthirty(30)daysofyourreceiptofthereplacementCRU.Seeyour

LenovoLimitedWarrantydocumentationforfulldetails.

ThinkPadcomputerscontainthefollowingtypesofCRUs:

–Self-serviceCRUs:TheseCRUsunplugorareheldbynomorethantwoscrews.Examplesofthesetypes

ofCRUsincludetheacpoweradapter,powercord,battery,andharddiskdrive.OtherSelf-serviceCRUs

dependingonproductdesignmayincludethememorymodule,wirelesscard,keyboard,andpalmrestwith

ngerprintreaderandtouchpad.

–Optional-serviceCRUs:TheseCRUsareisolatedpartswithinthecomputerthatareconcealedbyanaccess

panelthatistypicallysecuredbymorethantwoscrews.Oncetheaccesspanelisremoved,thespecic

CRUisvisible.

•FRUsmarkedwith

OPareavailableasoptions.

105
