1010Batterypack
Importantnoticeforreplacingabatterypack:
LenovoThinkVantageToolboxhasanautomaticbatterydiagnosticthatdeterminesifthebatterypack
isdefective.AbatterypackFRUshouldnotbereplacedunlessthisdiagnosticshowsthatthebattery
isdefective.
Theonlyexceptiontothisisifthebatterypackisphysicallydamagedoracustomerisreportingapossible
safetyissue.
IfLenovoThinkVantageToolboxisnotinstalledinthecomputer,thecustomershoulddownloadthisprogram
beforeanon-physicallydamagedbatterypackisreplaced.Notethatthereplacementofaphysically
damagedbatterypackisnotcoveredbythewarranty.
Removalstepsofthebatterypack
DANGER
Useonlythebatteryspeciedinthepartslistforyourcomputer.Anyotherbatterycouldignite
orexplode.
Unlockthebatterylatch1.Holdingthebatterylockleverintheunlockedposition2,removethebattery
packinthedirectionshownbyarrow3.
3
21
Wheninstalling:Installthebatterypackalongthesliderailsoftheslot.Thenmakesurethatthebattery
releaseleverisinthelockedposition.
1020Opticaldriveortravelcover
Foraccess,removethisFRU:
•“1010Batterypack”onpage58
58HardwareMaintenanceManual
