7-55
SYSTEM SETTINGS
Contents
User Count
This displays the total number of pages printed by each user.
When the [User Count] key is touched, the following screen appears.
• [Select All Users] key
This selects all users.
• [Show] key
This shows the counts of the selected user.
• [Delete] key
Use this to reset the counts of the selected user.
• User List
This shows the factory-stored users and the currently
stored users. To select a user, select the user name.
Showing user count
Select a user in the above screen and touch the [Show] key. The counts of that user will appear.
User Count
Back
Administrator
Other User
User
Name 1
Name 2 Name 3
Name 4
Name 5
Name 6
Name 7
Select All Users Show Delete
ABCD EFGH IJKL MNOP QRSTU VWXYZ etc.
ABC
Search Number
Index Switch
Sorting Order
All
1
2
Item Settings
Next This shows the next user (in the order of the registration numbers).
Previous This shows the previous user (in the order of the registration numbers).
Show Counts The counts and the number of pages remaining of the selected user are shown by function.
Page Limit The page limit set for the user appears in parentheses below the count.
• Counts of devices that are not installed do not appear.
• A user count can be saved in the screen that appears when [User Control] - [User Count] - [Save User Count] is selected
in the Web page menu.
