Other convenient functions
Convenient management functions
z Forward a received fax to a network address
z Print a list of transmission destinations
Convenient functions
z Scan a thin original
z Select a transmission destination from a global address book
z Send at a specified time
z Give priority to a transmission
z Send in USB memory mode
