REPLACING SUPPLIES AND MAINTENANCE
12
Close the front cover.
Take care that your fingers are not pinched when closing the cover.
13
Turn on the power.
Switch the main power switch "ON" and press the [POWER] key ( ) on the
operation panel to turn on the operation panel power.
mxc401_us_saf.book 49 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
