45
REPLACING SUPPLIES AND MAINTENANCE
4
Make sure that the cleaner at the tip of the cleaning
tool is not dirty.
If the cleaner is dirty, remove the cleaner and replace it with a clean
one. For the procedure for replacing the cleaner, see steps 5 through 7.
If the cleaner is not dirty, go to step 8.
5
Pull out the replacement cleaner from the toner
collection container.
Cleaner
mxc401_us_saf.book 45 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
