Using PC Cards
To register a PCMCIA application program, do the following:
1.
Select the type of PC Card on which the application program is
to run.
2.
Type the application name in the Object List box or
drag and
drop
the icon of a program in the workplace of the Object List.
RegisterObject
SelectaCardType
Memory
OK
Help
V
ObjectList
Drag&DropWorkplaceObjectbelow.
Launch...
AutomaticallyasCardisReady.
AutomaticallyasCardisInserted.
ByManualOperation.
Launch
Remove
3.
Select a choice from the Launch... box to run the application
program automatically or manually.
Help is available on most menu screens for additional information.
68 IBM ThinkPad 755CX User's Guide
