Installing the DAA/Telephony Kit
7
Connect the cables:
DANGER
To avoid shock hazard, do not connect the
telephone cable to or disconnect it from the
computer during electrical storms.
Note:
Both ends of the DAA interface
cable are identical.
a)
Connect one end of the DAA interface cable 1 to the
connector plug with the round receptacle.
b)
Connect the other end of the DAA interface cable 2 to
the round receptacle of the DAA.
c)
Connect the connector 3 of the ferrite-core end of the
telephone cable to the square receptacle of the DAA.
d)
Connect the other end of the telephone cable to the
telephone outlet 4 on the wall.
Telephone
Outlet
Core
DAA
After you have completed attaching the modem/fax port, install the
necessary software by referring to the manual that came with the
option package.
Refer to “Using the Telephony Function” on page 84 for information
about how to use the Mwave telephony features.
158 IBM ThinkPad 755CX User's Guide
