Installing the Mwave Support Software
Installing the Mwave Support Software
Note:
If you have multiple operating
systems, you might need to install
multiple versions of the Mwave
support software. For example, to
enable DOS and Windows
applications for Mwave functions,
two separate Mwave support
software installations are required:
one for DOS and one for Windows.
When installing an operating system, you must install the Mwave
support software.
The Mwave support software is supplied in the Mwave DSP
Features Diskettes or in the hard disk drive of your computer.
If the Mwave DSP Features Diskettes were not supplied with
your computer
, the support software is contained on the hard
disk drive. See the READ.ME file in the root directory of the
hard disk to install the Mwave DSP support software.
If the Mwave DSP Features Diskettes were supplied with your
computer
, install the Mwave support software as follows:
– For OS/2, see “Installing for OS/2.”
– For DOS, see “Installing for DOS” on page 194.
– For Windows, see “Installing for Windows” on page 195.
OS/2
Installing for OS/2
Before installing the Mwave support software for OS/2, install
Multimedia Presentation Manager/2 (MMPM/2), which comes with
OS/2 V.2.11. Refer to the
OS/2 Version 2.11 Installation Guide
for
instructions.
To install the Mwave support software for OS/2, do the following:
1
Turn on the computer; then start OS/2.
Note:
To open the OS/2 full screen:
1.
Select OS/2 System.
2.
Select Command Prompts;
then select OS/2 Full Screen.
2
Open the OS/2 full screen.
3
Insert the Mwave DSP Features Diskette 1 for OS/2 into
the diskette drive.
4
Type A:SETUP; then press Enter.
The installation window appears on the screen.
5
Follow the instructions on the screen.
192 IBM ThinkPad 755CX User's Guide
