AR-FX8 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-4

3. PWB

1 Modem control PWB FAX communication control

2 FAX FLASH ROM PWB FAX control program

3 FAX power PWB Supplies power to the FAX unit.

4 TEL/LIU PWB TEL line communication control

5 FAX I/F PWB (Installed to the machine side) Connection between FAX and MFP controller

6 FAX extended memory (Installed to FAX I/F PWB) <AR-MM9>
