A-99 Color Measurement Instruments

Sharp AR-C360P EFI Color Guide - 99

4. Attach the connector to the computer.

For a Windows computer, insert the 8-pin mini-DIN end of the

interface cable into the 9-pin DB9 Connector cable adapter. Insert

the 9-pin end into the COM1 or COM2 port on the computer and

tighten the screws. If the available port on your computer is 25-

pin, you must use the 8-pin-to-25-pin adapter.

Square

Unused connector

Connect to

computer

Interface cable

Connect to adapter
