Category Description HP ProBook 6560b

Notebook PC

HP EliteBook

8560p

Notebook PC

Three WLAN antennas built into display assembly √

Supports “no WLAN” option √√

Supports the following WLAN formats:

● Broadcom 802.11 b/g/n, 1×1

●

Broadcom 802.11 a/b/g/n, 2×2

●

Intel Centrino Advanced N 6205, 2×2 a/b/g/n

√√

●

Intel Centrino Wireless-N 1000, 1×2 b/g/n √

● Atheros 802.11 a/b/g/n 3×3 √

●

Intel Centrino Ultimate-N 6300, 3×3 a/b/g/n √

Integrated WWAN options by way of wireless module:

Two WWAN antennas built into display assembly (world-

wide 5 band, in WWAN panels only)

√√

Subscriber identity module (SIM) security (customer-

accessible in battery bay)

√√

Supports “no WWAN” option √√

Supports the following WWAN modules:

● Qualcomm Gobi 3000 HSPA/CDMA with GPS

●

Ericsson 5521 HSPA+

√√

Integrated personal area network (PAN) options by way of Bluetooth® module:

Supports “no PAN” option √√

Integrated Bluetooth 2.1 √√

External media card One ExpressCard/54 slot √√

Integrated Media Card Reader with SD, MMC support √√

Ports Audio-in (stereo microphone) √√

Audio-out (stereo headphone) √√

DisplayPort 1.1a √√

DisplayPort 1.2 √√

RJ-11 (modem) √√

RJ-45 (Ethernet, includes link and activity lights) √√

USB 3.0 √

USB 2.0 (3) √

USB 2.0 charging port √

eSATA/USB 2.0 combo port √√

4 Chapter 1 Product description
