Starting the Imaging Software

CS 9300 Imaging System User Guide (SM748)_Ed 01 4–3

2 Enter the required patient information. The Last name, the First name and the Date

of birth fields are required.

3 From the menu bar, select Picture > Insert Picture to add a *.tif or *.bmp picture of

the patient to the record. Select the picture from your directory and click Open.

4 Click OK to save. The patient record is automatically assigned a 7-digit number

starting with a letter (for example, M0000001).

5 Click to access the Imaging window.

6 Select an image acquisition.

Accessing the Acquisition Interface

To access the Acquisition interface, follow these steps:

1 In the Imaging window, from the toolbar, click to access the Panoramic

Acquisition window, or, click to access the 3D Acquisition window.

2See the chapter “Acquiring an Image” to launch an acquisition.
