Acquisition Interface

3–10 IMAGING SOFTWARE OVERVIEW

Figure 3–8 Ear Program Pane

Ear exam options:

Right ear: Acquisition of right ear.

Left ear: Acquisition of left ear.

Right & Left ears: Acquisition of both right and left ears.

Image program options:

Fast Acquisition button: Minimizes the acquisition time to help avoid patient

movement.

High Quality Acquisition button: Longer acquisition time with more projections for

maximum quality image.

Extended temporal bone area: Enables capturing more structures around the

temporal bone.

Right & Left ear acquisition: Only available with the Right & Left ears program.
