X-Ray Remote Control Overview

CS 9300 System User Guide (SM748)_Ed 01 2–7

X-Ray Remote Control Overview

The x- ray remote control enables you to launch a radiological image acquisition via the

exposure button from outside the x-ray room. You must press and hold the exposure

button until the end of acquisition. Premature release of the exposure button interrupts

the acquisition.

Figure 2–6 X-Ray Remote Control

1 Exposure button: launches image acquisition.
