Timetable Editor

●Registering panel control in a timetable

1. Click the [Panel Control] tab.

A list of panel control commands will be displayed.

Therearetwocategories:“CommandName”and“InputSource”.Commandsareasfollows:

Command Description

Turn On Display *

Turns the panel (monitor) power ON.

Turn Off Display Puts the panel (monitor) into standby mode.

Switch Input Source

(Input“No.”)

Switches the panel (monitor) input source.

TV *

Switchtheinputsourceofthepanel(monitor)to“TVinput”.Thechannelatthe

timeofswitchingtotheTVcannotbespeciﬁed.Thechannelthatwasselectedby

the TV immediately before switching is displayed.

*1 ItcannotbeusedwiththeLB-46GX35andLB-52GX35.

*2 ItcannotbeusedwiththeSHARPLCDmonitor(PNseries)andtheLB-1085.

 •Thecommandssupportedbythepanel(monitor)

canbecheckedwith“Tableofsupportingpanel

controls.”

•Todisplay“Tableofsupportingpanelcontrols,”

click the button (

)“AboutPanelSupport”atthe

lower left of the panel control command list. Or, click

[AboutPanelSupport]from[HelpMenu].

Thecontentsof“Tableofsupportingpanelcontrols”areasfollows:

Menu option Description

RC-232C

Indicates the cable to be used for the connection (straight cable or cross cable).

Indicates transmission speeds supported.

LAN IndicateswhetherLANconnectionissupported.

Turn On

Indicateswhetherthe“TurnOnDisplay”panelcontrolcommandissupported.

Turn Off

Indicateswhetherthe“TurnOffDisplay”panelcontrolcommandissupported.

GetStatus

IndicateswhetherGetStatus(

p.101)issupported.

H/WErrorDetection Indicates whether IDP hardware error detection is supported.

TimeSynchronization

IndicateswhetherTimeSynchronization(

p.91,92)issupported.

Input“No.” Indicates which input of the panel (monitor) is supported.

TV Indicates whether TV input is supported.

Creating a timetable
