114

Status Monitoring Tool

Acquiring and displaying panel status

4. A screen like the one on the right will appear. Check that

the distribution was successful and click [Close].

●Displaying detailed information for a panel

1. Select a group from the group tree, and then select a

panel from the panel list.

2. From the [Panel] menu click [Property], or alternatively, click

The[Panelproperty]dialogboxwillappear.

3. Check the settings, and click [Close].

 •Todisplay“Panel(PNseries)status,”check“Statusacquisitionofpanel(PNseries)”inthe[Setting

ofoperationenvironment]dialogbox(

p.116)
