2-53 Using the EFI Densitometer ED-100

Sharp AR-C360P EFI Color Guide - 53

16. Click Apply in the Calibrator window to implement the new

calibration measurement.

17. Click OK in the Information dialog box.

This completes the Fiery calibration process.

Using the EFI Densitometer ED-100

The EFI Densitometer ED-100 is a hand-held instrument that

measures the density of printed ink and toner. Like the DTP32, the

ED-100 is a reflection densitometer that you can use to calibrate

the Fiery.

Setting up the ED-100

To use the ED-100 for calibration purposes, you must first set it up

for use with your computer. For complete instructions on setting

up the ED-100, see the documentation that is included with the

instrument.

The following illustration shows the components of the ED-100.

Indicator

Sample aperture

(underneath)

Measure button
