A-107 Color Measurement Instruments

Sharp AR-C360P EFI Color Guide - 107

4. Plug the small connector on the adapter cable into the side of the

X-Rite DTP32 and plug the AC adapter into a wall outlet.

5. Turn on the computer.

6. Calibrate the DTP32 (see the following section).

7. Calibrate the Fiery using ColorWise Pro Tools and the DTP32 (see

page 2-61).

Calibrating the DTP32

You will need the black-and-white X-Rite Auto-Cal Strip included

with the densitometer. Calibrating the densitometer does not

require ColorWise Pro Tools.

To calibrate the X-Rite DTP32

1. Connect the densitometer to the computer and supply power (see

page A-105).

2. From the Main Menu on the X-Rite DTP32 display, press the p1

key once to reach p2.

3. Press the cal key.

Calibrating motor speed is displayed, followed by the words INSERT

CAL STRIP

AC adapter

Small connector
