55
This is used to prohibit the storing of destinations.
Storing from the machine, storing from the Web page,
and storing from a computer can each be separately
prohibited.
Disable Registering Destination
from Operation Panel
This disables address control from the machine.
Configure the setting for each of the following items:
•Group
•E-mail
• Internet Fax
•Fax
Select All: Select all items.
Clear Checked: Clear all selections.
Disable Registering Destination on
Web Page
This disables address control from the Web pages.
Configure the setting for each of the following items:
•Group
•E-mail
• FTP
•Desktop
• Network Folder
• Internet Fax
•Fax
Select All: Select all items.
Clear Checked: Clear all selections.
Disable Registration Using
Network Scanner Tool
This disables address control from the Network Scanner
Tool.
These settings are used to disable the following
transmission operations.
Disable [Resend] on Image Send
Mode
This setting disables the [Resend] key in the base
screen of image send mode.
Disable Selection from Address
Book
This disables the selection of destinations from the
Address Book.
Configure the setting for each of the following items:
• E-mail
• FTP
• Desktop
• Network Folder
• Internet Fax
•Fax
Select All: Select all items.
Clear Checked: Clear all selections.
Disable Direct Entry
This prohibits the direct entry of addresses.
Configure the setting for each of the following items:
• E-mail
• Internet Fax
•Fax
Select All: Select all items.
Clear Checked: Clear all selections.
Disable PC-I-Fax Transmission
(When the Internet fax expansion kit is installed.)
This prohibits PC-I-Fax transmission.
Disable PC-Fax Transmission
(When facsimile expansion kit is installed.)
This prohibits PC-Fax transmission.
Settings to Disable Registration
Settings to Disable Transmission
