HOW TO USE THE NETWORK SCANNER FUNCTION

SETTING THE LIGHT SOURCE COLOR

When scanning in black and white mode, you can set the light source color.

For example, if you do not wish to scan the red parts of an original, set the light source color to "RED". ("WHITE" will

cause all colors to be scanned.)

Select scan mode, place the original (steps 1 to 3 on page 20

), and then follow the procedure below.

The factory default setting for the light source color is "WHITE".

If you need to change the light source color, follow these steps.

Press the [SPECIAL FUNCTION] key in

scan mode.

Perform this operation from the

base screen of scan mode.

When the [SPECIAL

FUNCTION] key is pressed, the

special function menu appears.

(To select scan mode, see step

1 on page 20

Select "LIGHT SOURCE" with the [ ]

or [ ] key.

Press the [OK] key.

Select the desired light source color

with the [ ] or [ ] key.

Press the [OK] key.

The setting is stored and you

return to the base screen.

ADJUSTING THE THRESHOLD VALUE

When scanning in black and white mode, you can adjust the threshold value. As the threshold value is increased,

black becomes stronger. As the threshold value is decreased, white becomes stronger.

Select scan mode, place the original (steps 1 to 3 on page 20

), and then follow the procedure below.

The factory default setting for the threshold value is "128".

To change the threshold value, follow these steps:

Press the [SPECIAL FUNCTION] key in

scan mode.

Perform this operation from the

base screen of scan mode.

When the [SPECIAL

FUNCTION] key is pressed, the

special function menu appears.

(To select scan mode, see step

1 on page 20

Select "B/W THRESHOLD" with the

[] or [] key.

The light source color can only be selected when the color mode is set to "B/W". (Page 27)

Note

DUPLEX

SPECIAL FUNCTION

ACC.

DUPLEX SCAN

PQR

DUPLEX

SPECIAL FUNCTION

DUPLEX SCAN

SPECIAL FUNCTION

B/W THRESHOLD

LIGHT SOURCE

VOID AREA

PAPER SIZE SET

GHI

BACK

LIGHT SOURCE

WHITE

RED

GREEN

BLUE

The threshold value can only be adjusted when the color mode is set to "B/W". (Page 27)

Note

DUPLEX

SPECIAL FUNCTION

ACC.

DUPLEX SCAN

PQR

DUPLEX

SPECIAL FUNCTION

DUPLEX SCAN

SPECIAL FUNCTION

B/W THRESHOLD

LIGHT SOURCE

VOID AREA

PAPER SIZE SET
