4-1

CHAPTER 4

TROUBLESHOOTING

AND MAINTENANCE

This chapter describes misfeed removal, user maintenance, etc.

Page

MISFEED REMOVAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

● General misfeed removal procedure . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

● Misfeed removal guidance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

● Misfeed in the paper feed area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

● Misfeed in the transport area, fusing area, and exit area . . . . . . . . . 4-6

● Misfeed in the duplex module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

USER MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

● Cleaning the scanner module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
