7-10

CHAPTER7

Staple cartridge replacement

The message “SLIDE THE FINISHER AWAY FROM THE COPIER

AND ADD STAPLES.” will appear when the staple cartridge is empty.

Replace the staple cartridge as follows:

While holding the finisher release lever, slide the finisher

away from the copier.

Lower the lock lever to unlock the stapler unit.

Turn the stapler unit to face up.

Hold the staple box release lever to unlatch the staple

box.

Remove the staple box.

Remove the empty staple cartridge from inside the

staple box.

Insert the new staple cartridge into the box until it clicks

in place.

●

Insert the new cartridge by aligning the arrows on the cartridge

with those on the box. Check that the cartridge locks in place by

pulling it slightly.

●

The cartridge holds 5,000 staples.

OPTIONAL EQUIPMENT

Finisher (AR-FN3)

FINISHER (AR-FN3)
