• GETTING STARTED• MAKING COPIES• SPECIAL FEATURES• STATUS INDICATORS• GENERAL INFORMATION• OPTIONAL EQUIPMENT 21328384665DIGITAL LASER COPIER/PRINTER

8GETTING STARTEDCopier installationCOPIER INSTALLATIONImproper installation may damage the copier. Please note the followingduring initial installatio

GETTING STARTEDGETTING STARTED9GETTING STARTEDCAUTIONS ON HANDLINGBe careful in handling the copier as follows to maintain the performance ofthis copi

10GETTING STARTEDLOADING COPY PAPERTo save space, this copier has been designed with an adjustable front-loadingtray, which is easily opened for paper

GETTING STARTEDGETTING STARTED11GETTING STARTEDChanging the copy paper size in the tray1Gently lift and pull out the paper tray until it stops.2Push t

12GETTING STARTED Loading copy paperLOADING COPY PAPER8To set the selected paper size, press the PAPER SIZEENTER key.●The selected paper feed location

13MAKING COPIESAUDITING ACCOUNTSIf this copier has been programmed in the auditing mode, it will not functionuntil an assigned 3-digit account number

14MAKING COPIESNORMAL COPYINGUsing the SPFStream feeding modeIf the stream feeding mode has been enabled using user programNo. 4, the SPF indicator wi

15MAKING COPIESNORMAL COPYINGNormal copying6Adjust the copy density.●This copier has three exposure modes to choose from — AUTOMATIC,MANUAL, and PHOTO

16MAKING COPIES1Turn the power switch on.●It will take about 35 seconds for the copier to warm up. However, youcan make desired settings and press the

17MAKING COPIES●For manual copy density adjustment, press the AUTO/MANUAL/PHOTO key to select MANUAL and adjust with the light ( ) anddark ( ) keys as

FOR YOUR RECORDS ...To protect against loss or theft, record and retain for reference thecopier’s serial number located on the back of the unit.Model

18MAKING COPIESREDUCTION/ENLARGEMENT/ZOOMReduction and enlargement ratios can be selected either automatically withthe AUTO IMAGE key or manually with

19MAKING COPIESREDUCTION/ENLARGEMENT/ZOOMReduction/enlargement/zoomManual1Place the original in the document feeder tray or on theoriginal table.2Use

20MAKING COPIESBYPASS FEED (special paper)The bypass tray is used to copy onto transparency film, labels, and otherspecial purpose papers. Up to 100 s

21MAKING COPIES4Press the TRAY SELECT key to select the bypass tray.5Leave the copy quantity at 0 if using special papers. Setthe number of copies if

22MAKING COPIESTWO-SIDED COPYINGTwo-sided copies can be made on this copier using the bypass tray.1Place the first original on the original table and

23MAKING COPIESSORT/GROUPThis copier has two sorter modes for different copying jobs: one sorts copies into setsmatching the sequence of the originals

24MAKING COPIESSort/groupSORT/GROUPCopying in the sort modeWhen copying in the sort mode, the original image will be stored in the copiermemory each t

25MAKING COPIES1Press the INTERRUPT key.●The copier will return to the initial settings.●If this copier has been programmed in the auditing mode using

26MAKING COPIES1Press the AUTO/MANUAL/PHOTO key to select thePHOTO mode.2Press and hold down the AUTO/MANUAL/PHOTO keyfor approximately 5 seconds.●The

27MAKING COPIES Toner save mode1Press the AUTO/MANUAL/PHOTO key to select theMANUAL mode.2Press and hold down the AUTO/MANUAL/PHOTO keyfor approximate

1GETTING STARTEDSPECIAL FEATURESMAKING COPIES GENERAL INFORMATIONOPTIONALEQUIPMENTCONTENTS PageGETTING STARTED●INTRODUCTION . . . . . . . . . . . . .

28SPECIAL FEATURES1Place the original in the document feeder tray or on theoriginal table.2Press the XY-ZOOM key.●The current value for the vertical d

29SPECIAL FEATURESXY zoomXY ZOOM5Use the PRESET RATIO selector ( , ) keys and zoom( , ) keys to change the copy ratio in the horizontaldirection in

30SPECIAL FEATURESB/W REVERSEThe B/W REVERSE feature is used to reverse black and white areas.●When the B/W REVERSE feature is selected, the exposure

31SPECIAL FEATURES1Place the originals on the original table with the centerof the two pages aligned with the paper size index (81/2 ). Close the plat

32SPECIAL FEATURESROTATION COPYINGIf user program No. 7 is set, the image of the original will rotate when theorientation of the original does not mat

33SPECIAL FEATURES1Set the originals face up in the document feeder tray.●The original table cannot be used for the 2 in 1 or 4 in 1 feature.2Use the

34SPECIAL FEATURES2 in 1 or 4 in 14Enter the desired pattern number using a numeric key.●The entered number will blink in the copy quantity display. F

35SPECIAL FEATURES1Place the original on the original table and close theplaten cover.●The SPF can also be used for this feature.2Press the ERASE key

36SPECIAL FEATURES4Set the number of copies.5Press the START key.EraseERASE

37SPECIAL FEATURESMargin shiftMARGIN SHIFTThe MARGIN SHIFT feature automatically shifts the text or image tothe right to increase the left margin by a

2GETTING STARTEDINTRODUCTIONThis copier has been designed to provide convenient copying features in a minimumamount of office space and with maximum o

38STATUSINDICATORS1Open the bypass tray. Lift slightly on the side cover andslide the cover out until it stops.2Push gently on both sides of the front

39STATUSINDICATORS Toner cartridge replacementTONER CARTRIDGE REPLACEMENT5Gently insert the toner cartridge along the guides untilit locks in place wh

40STATUSINDICATORSThe copier will stop when a misfeed occurs. The misfeed( ) indicator will blink, and blinking red misfeed locationindicators will in

41STATUSINDICATORS Misfeed removalMISFEED REMOVALRoller3If the misfed original cannot be removed in steps 1 and2, remove the misfed original from the

42STATUSINDICATORSMISFEED REMOVAL Misfeed removalIf the misfed paper is seen from this side, proceed to “C. Misfeed in the transport area”.If paper is

43STATUSINDICATORSMISFEED REMOVAL Misfeed removalRoller rotating knobFusing unit release levers2Turn the roller rotating knob in the direction of thea

44STATUSINDICATORSMISFEED REMOVAL Misfeed removal3Close the side cover by pressing the handle on thecover.●The misfeed ( ) indicator will go out.Misfe

45STATUSINDICATORS Developer required/Maintenance requiredMAINTENANCE REQUIREDWhen the indicator lights up, service by an authorized SHARP servicete

46GENERAL INFORMATIONUser programsUSER PROGRAMSThe user programs allow the parameters of certain functions to be set,changed, or canceled as desired.L

47GENERAL INFORMATIONSetting the user programs1Press and hold the light ( ) key for more than 5seconds until all the alarm indicators (, , , ,and )

GETTING STARTEDGETTING STARTED3GETTING STARTEDMain featuresMAIN FEATURESHigh-speed laser copying●First-copy time is only 7.2 seconds (except in a powe

48GENERAL INFORMATIONUSER PROGRAMS4Select the desired parameter using the numeric keys.●The entered parameter number will blink on the right side of t

49GENERAL INFORMATIONUSER PROGRAMSUser programsSettings for auditing accountsSetting of user programs No. 10 to 15 varies with the program number. For

50GENERAL INFORMATIONUSER PROGRAMSUser programsProgram No. 12: Account number changeProgram No. 12 is used to change account numbers. When program No.

51GENERAL INFORMATIONUser programsUSER PROGRAMSProgram No. 14: Number of copies per accountProgram No. 14 is used to display the total number of copie

52GENERAL INFORMATIONUSER PROGRAMSUser programsProgram No. 15: Resetting accountProgram No. 15 is used to reset all accounts or to reset any desired i

53GENERAL INFORMATIONPOWER SAVE MODESThe copier has two power save modes to reduce overall power consumptionthereby reduce the cost of operation. In a

54GENERAL INFORMATIONSetting the power save modesThe time that elapses before the copier enters a power save mode after anyoperation is made can be se

55GENERAL INFORMATIONUSER MAINTENANCEProper care is essential for clean, sharp copies. Please take a few minutes toregularly clean your copier.Origina

56GENERAL INFORMATIONTransfer charger cleaningIf copies start becoming streaky or blotchy, the transfer charger may be dirty.Clean the charger using t

57GENERAL INFORMATIONProblem Solution●Copier plugged in?●Power switch ON?●Copy density properly adjusted?●Is the original placed face up in theSPF o

4GETTING STARTEDPART NAMES AND FUNCTIONSOverall layoutDocument feeder coverOpen to make copies from the original table.Original tableAll originals whi

58GENERAL INFORMATIONProblem SolutionCopier trouble?COPIER TROUBLE?COPY/FAX keyThe COPY/FAX key is used to switchbetween the FAX and COPY modes.For

59GENERAL INFORMATIONCopier trouble?Self-diagnostic functionAn automatic self-diagnostic function is built into the copier. Should thecopier malfuncti

60GENERAL INFORMATIONSUPPLIESTypes and sizes of copy paperSize Weight Capacity Special paper(21 lb. bond paper)Paper tray 5-1/2" x 8-1/2"* 1

61GENERAL INFORMATIONSUPPLIESGenuine supplies statementStandard supplies for this copier that are to be replaced by the user are copypaper and toner c

62GENERAL INFORMATIONType DesktopCopy system Dry, electrostatic transferOriginals Sheets, bound documentsOriginal sizes Max. 11" x 17"Copy s

63GENERAL INFORMATIONSPECIFICATIONSSpecificationsOverall dimensions 23-15/64" (W) x 20-29/32" (D)(with bypass tray folded) (590 mm (W) x 531

64GENERAL INFORMATIONMEMO

65OPTIONALEQUIPMENTOPTIONALEQUIPMENTCONTENTSPage●SYSTEM CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 66●250-SHEET PAPER FEED U

66OPTIONALEQUIPMENTSYSTEM CONFIGURATIONA number of options are available for the copier which allow you toconfigure a copier system to meet your parti

67OPTIONALEQUIPMENTLoading copy paperThe method of loading copy paper for the paper trays of these paper feed unitsis the same as for the paper tray i

GETTING STARTEDGETTING STARTED5GETTING STARTEDPART NAMES AND FUNCTIONSDocument feeder trayHolds up to 30 originals.Original guidesAdjust to the size o

68OPTIONALEQUIPMENTMisfeed removalThe copier will stop when a misfeed occurs. The misfeed ( ) indicator andthe red indicator which indicates the paper

69OPTIONALEQUIPMENTSpecificationsCopy paper size 8-1/2" x 11" to 11" x 17"Paper weight 15 lbs. to 21 lbs.Paper capacity One paper

702250-sheet paper feed unit . . . . . . . . . . . . . . . . . . . . . . . 672 in 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

71RReduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Replacement– toner cartridge . . . . . . . . . . . . . . . . . .

72 Date Issued: Nov. 1, 2000MATERIAL SAFETY DATA SHEETMSDS No. F-00991Section 1. Product IdentificationProduct:AR-201NT/T/FT/ST (Black Toner)Section 2

73Section 6. Physical Chemical CharacteristicsBoiling / Melting Point: Not applicable Specific Gravity: 1.1Vapor Pressure: Not applicable Solubility i

74Date Issued: Nov. 1, 2000MATERIAL SAFETY DATA SHEETMSDS No. F-30991Section 1. Product IdentificationProductAR-201ND/DV/SD (Black Developer)Section 2

75Section 6. Physical Chemical CharacteristicsBoiling / Melting Point: Not applicable Specific Gravity: about 7.3Vapor Pressure: Not applicable Solubi

MEMO

WARNING:FCC Regulations state that any unauthorized changes or modifications tothis equipment not expressly approved by the manufacturer could void th

6GETTING STARTEDOperationpanelPART NAMES AND FUNCTIONSINTERRUPT key and indicator (p. 25)Interrupts a copy run.Copy quantity displayDisplays the speci

PRINTED IN CHINA2002B KS TINSE0000QSZZAR-164SHARP ELECTRONICS CORPORATIONSharp Plaza, Mahwah, New Jersey 07430-2135.SHARP CORPORATIONwww.sharp-usa.

GETTING STARTEDGETTING STARTED7GETTING STARTEDPART NAMES AND FUNCTIONSPress and hold down the key. 12,345 sheets output1st display2nd displayNote: 11&
