STATUS

INDICATORS

MISFEED REMOVAL

Misfeed removal

Close the side cover by pressing the handle on the

cover.

●

The misfeed ( ) indicator will go out.

Misfeed in the paper tray

Before opening the paper tray, be sure to open the bypass tray, lift slightly

on the side cover and slide the cover out until it stops, and then perform steps

1 to 3 described in the “A. Misfeed in the paper feed area” section.

Gently lift and pull out the paper tray and remove the

misfed paper.

Close the paper tray.

Lift slightly on the side cover and slide the cover out

until it stops. Close the side cover by pressing the

handle on the cover.

●

The misfeed ( ) indicator will go out.
