STATUS

INDICATORS

The copier will stop when a misfeed occurs. The misfeed

( ) indicator will blink, and blinking red misfeed location

indicators will indicate the approximate misfeed location.

If paper is accidentally torn during removal, be sure to

remove all pieces.

Be careful not to damage the photoconductive drum.

For misfeeds in optional equipment, see their section of the

operation manual.

First confirm the misfeed location.

MISFEED REMOVAL

Misfeed removal

( P. 40)

( P. 41, 44)

( P. 68)

Misfeed in the SPF

If an original misfeed occurs in the SPF, the copier will

stop and the red indicator which indicates an original

misfeed will blink.

Open the feeding roller cover and pull the original gently

to the left and out from the document feeder tray. Close

the feeding roller cover.

If the misfed original cannot be removed in step 1, open

the right side cover and remove the misfed original.

Close the right side cover.

Feeding roller cover

Right side cover

Location A

Location B
