Operation

Saving and Selecting Adjustment Settings

This projector allows you to store up to seven adjustment

settings for use with various computers. Once these

settings are stored, they can be easily selected each

time you connect the computer to the projector.

Saving the adjustment setting

(Slide the MOUSE/ADJUSTMENT switch

on the remote control to the ADJ. position.)

1 Press MENU.

2 Press ß/© to select “Fine Sync”.

3 Press ∂/ƒ to select “Save Setting”, and then press

©.

4 Press ∂/ƒ to select the desired memory location of

the setting.

5 Press ENTER to save the setting.

6 To exit from the GUI, press MENU.

Selecting a saved setting

(Slide the MOUSE/ADJUSTMENT switch

on the remote control to the ADJ. position.)

1 Press MENU.

2 Press ß/© to select “Fine Sync”.

3 Press ∂/ƒ to select “Select Setting”, and then press

©.

4 Press ∂/ƒ to select the desired memory setting.

5 Press ENTER to select the setting.

6 To exit from the GUI, press MENU.

• If the memory position has not been set, the resolution and

frequency will not be displayed.

• When selecting the stored adjustment setting with “Select

Setting”, the computer system should match the stored

setting.

• This function cannot be used when inputting DIGITAL signal.

(GUI) On-screen Display

Computer Image Adjustments

MOUSE

ADJ.

MOUSE

ADJ.

2, 3, 4

1, 6

Projector Remote control
