Basic Operation

Selecting the Transmission Speed (RS-232C)

This menu allows you to adjust the transmission speed

of the RS-232C connection by selecting the baud rate.

1 Press MENU.

2 Press / to select “Options”.

3 Press

/ to select “RS-232C”, and then press

4 Press

/ to select the desired baud rate.

5 Press ENTER to save the setting.

6 To exit the GUI, press MENU.

• Make sure that both the projector and computer are set for

the same baud rate. Refer to the computer’s operation

manual for instructions for setting the baud rate.

(GUI) On-screen Display

1,6

2,3,4
