Lift knob and then remove any misfed paper.

( is indicated in the illustration of step 2 on page 7-18.)

Paper Misfeed in the Saddle Stitch Unit (optional)

Remove any misfed paper from the paper exit area.

Open the entrance cover of the saddle stitch unit.

When installing the optional inserter, open the lower

cover of the inserter.

* Only when the saddle stitch finisher (AR-F12) is installed.
