Remove the seals around the holes.

Grasp the edge of each seal and pull it out toward you.

There are 5 seals. Remove all of the seals.

Plug the holes.

Grasp the edge of each black seal and insert it into a hole in the

box to plug the hole.

• There are 5 seals. Plug all of the holes.

• Do not discard the waste toner box. Place it in a plastic bag and keep it until your service technician comes to

perform maintenance. Your service technician will collect the waste toner box.

Install the new waste toner box.

Insert the box from above at a slant. (The direction opposite to

when you removed it.)

Push the waste toner box into the

machine.

Push the box in until it clicks into place.
