MISFEED REMOVAL

COPIER TROUBLE?

Misfeed in the upper paper tray

Before opening the upper paper tray, be sure to open the bypass tray and the side cover and then

perform steps 1 to 3 described in the "A. Misfeed in the paper feed area" section.

Pull out the upper paper tray and remove the misfed paper.

Close the paper tray.

Open and close the side cover to cancel the misfeed display.

●

You can also cancel the misfeed display by opening and closing the front cover.

●

Confirm that the misfeed display has been cleared.

Misfeed in the lower paper tray

Grasp the handle of the lower side cover and gently open the cover.
