IBX-530B-270 Embedded System

Page 14

 Supports C0/C1(e)/C2(e)/C4(e)

 L2 Dynamic Cache Sizing

 Advanced power management features including Enhanced Intel

SpeedStep® Technology

 Execute Disable Bit support for enhanced security

3.3 Intel 945GSE Northbridge Chipset

The Intel® 945GSE Graphics and Memory Controller Hub (GMCH) supports the

embedded Intel® Atom™ N270 processor. The Intel® 945GSE is interfaced to the

processor through a 533 MHz FSB.

3.3.1 Intel® 945GSE DDR2 Controller

There is one 200-pin DDR2 SO-DIMM socket on the motherboard preinstalled with one

1.0 GB DDR2 SO-DIMM. The socket supports DDR2 SO-DIMM with the following

specifications:

 Maximum Memory supported 2 GB

 Support for DDR2 at 400 MHz and 533 MHz

 No support for Dual-Channel Interleaved mode of operation

 Enhanced Addressing support (Swap only)

The SO-DIMM socket is shown in

Figure 3-1 below.
