IBX-530B-270 Embedded System

Page 108

B.1 Peripheral Interface Connectors

NOTE:

The jumpers and connectors shown in the section below are those

jumpers and connectors that are relevant to the configuration and

installation of the embedded system.

The IBX-530B-N270 embedded system motherboard, the AFLMB-945GSE comes with a

number of peripheral interface connectors. The pinouts for the connectors that are used in

the IBX-530B-N270 are listed below:

PIN NO. DESCRIPTION

1 Battery +3.3V

2 GND

TableeB-1: Battery Connector Pinouts (BT1)

Pin No. Description Pin No. Description

1 GROUND 26 CD1

2 D3 27 D11

3 D4 28 D12

4 D5 29 D13

5 D6 30 D14

6 D7 31 D15

7 CE 32 CE2

8 A10 33 VS1

9 OE 34 IOR

10 A9 35 IOW

11 A8 36 WE

12 A7 37 IRQ

13 VCC1 38 VCC

14 A6 39 CSEL

15 A5 40 VS2

16 A4 41 RESET
